Description

Designed as a guide to mill pass setting device for use in high-speed wire rod block. The portable optical setting device is mounted inside the roller or static entry guide holder or support.

In this way the optical device is showing the actual position of the guide in relationship to the roll pass.

A very user-friendly device designed to be used in the rolling mill environment.

Guide Features

• Aircraft quality aluminium body.
• Strong rolling mill environment design.
• Simple 1 x 2, 1 x 3 and 1 x 5 magnification optical system
• Replaceable magnifying lens.
• Simple reflecting mirror.
• Frosted glass or acrylic viewing screen.
• Simple mill use light source.
